Renk Grup RG-E1800 Road Sweeper Vehicle
Renk Grup RG-E1800 Road Sweeper Vehicle

RG-E 1800 SWEEPING MACHINE

RG-E1800 Electric Vacuum Hydrostatic Road Sweeper with articulated is a new generation vacuum sweeping vehicle produced independently with its technical features against its competitors. It has a powerful functions with aesthetic appearance, which can achieve perfect cleaning of general motorways, sidewalks, large commercial plazas, high-end properties, parks, etc.

High pressure and inclined centrifugal fan design, equipped with a state-of-the-art DC asynchronous motor. The stainless steel garbage waste tank is integrated into the anti-corrosion steel vacuum tank.

With its Long-lasting, high-capacity 600AH lithium battery and air conditioning feature, AC and DC integrated fast charging system, provides an opportunity to use of more than 25% according to the daily operating hours.


- Brochure
Technical Specifications
Transaction
High Suction Power
Voltage
72 V 600 AH
AC Motor
72 V 7.5kW AC Traction Motor
AC Controller
72 V 450A
Battery
Lithium-iron phosphate battery 72 V600 Ah Super large capacity, super long endurance, long time warranty
High pressure leaning control system
High pressure AC cleaner system, small and welan gum cement with 80-120 bar pressure. Easily removes stubborn stains.
Automatic Discharging
1800 L
Dumping Height
1250 mm
Dust Suppression
Full water cycle dust control system, multi-stage water cycle usage control action is more perfect, and settled the dust
Hot and Cold Air Conditioners
The operator seat is equipped with heating and cooling system
Car Charger All vehicles are equipped with an on-board charger that can be choosed the fast and slow charing mode.
Steering Method
Power steering, discrete object, little turning angle, flexible and easy control
Car Body
High-strength, impact-resistant manganese steel, steel tube with particular shape, frame structure
Frame
High-strength frame structure, double anti-rust function
Net Weight
2000 kg (with battery)
Speed Control
16 km / h
Dimensions (W x L x H)

3900mm x 1450mm x 2150mm

Maximum Cleaning Width
2000mm
Water Tank
210 L

Two types of charging systems are integrated into the RG-E1800 Vacuum Sweeping Vehicle puts into service. AC is used for on-board charging system. This system is used to charge the vehicle at night. Other system DC, is an off-board charger system directly connected to the lithium battery system to quickly meets the needs of the long-term charging of the lithium battery system. The fast charging is used to quickly recharge the battery during the day, and the slow charging is used at night to ensure the balanced charging of the lithium battery and extend service life.

RG-E1800 Sweeping Machine with battery is used for dust control occuring through vacuum hose by water recycling system in the garbage waste tank without water recycling system with heat exchanger and filter mechanism. The water recycling dust control system effectively removes by bringing the water usage of vehicle economically into the forefront and make productive the dust control action in the waste tank. Having an 1.5 M3 large capacity garbage waste tank provides long-term sweeping function.

In the cabin, have the feature of maneuverability enabling ease of use to operators and high functioning joystick with its adjustable feature. In addition, ensures to changeover the brush controls quickly. In this operation process, ensures that the brushes reach the floors in a proper manner, and offers the sweeping brush to be stopped and picked up by the system with an adjustable button single depend on brush width. RG-E 1800 Road Sweeping Vehicle is a high technology sweeper equipped with an articulated feature and an electronic smart system.

All vehicles use the Vehicle CAN mastering. and integrates the lithium battery system, electronic control system and smart charging system. The instrument panel integrates and displays related parameters and fault codes of each system. The touch display is easy to use and functional. Hydraulic garbage reservoir, which is capable of automatically lifting and discharging, is made of 3 mm stainless steel garbage reservoir and impact-modified. With its discharge angle up to 95 degrees, has the feature of quickly discharging the wastes in the tank from a height of 1400 mm into the garbage container and garbage carter.

The cab design is made of impact resistant high-strength steel and dumper glass technology. The RG-E 1800 is designed to provide comfort to the users by having the feature of openable windows in the doors along with its impact resistant tempered glass structure with wide-angle visibility distance.

It is produced by integrating the module charging system with its articulated and articulated frame structure,high maneuverability steering capability and electric hydraulic centered power system. With its high maneuverability feature, offers the ability to return in confined space.

The lighting system equipped with the automobile system, far and near headlights, warning lights, front and rear turn signal lights, rear taillight and brake warning lights, LED work lamps, tail lights and cab dome lights is a business machine which is travellable confidingly through traffic.



RG- E 1800 Hydrostatic Articulated Sweeping Vehicle have the feature of hydraulic steering gear, sweeping brush which is operated independently from each other, smart system garbage reservoir, AC asynchronous motor, silent and gradually increasing vacuum fan system, touch screen AC smart system and fault alarm function.
